Browse our commonly stocked hose products below. Call or email us to request a custom length assembly with end connection options including camlocks, threaded, flanged, sanitary & more
CHECK CHEMICAL & MATERIAL COMPATABILITY
The information provided on this website is for general informational purposes only. If you have questions about a specific product, we recommend contacting us directly for confirmation.
T202AA - Water Suction & Discharge
-
Working Pressure: 150 PSI
-
Service Temperature Range: -40 °F to 212 °F
-
Construction:
-
Cover - Black EPDM
-
Tube - Black EPDM
-
Reinforcement - Flexible steel helix wire
-
-
General Applications: Suction & discharge of non-corrosive liquids for irrigation, construction, fertilizers and lasso acid solutions

Available in
1" I.D. through 12" I.D.
VINYL FLOW - Layflat Water Discharge
-
Premium PVC drip irrigation & water discharge
-
Service Temperature Range: -5 °F to 170 °F
-
Construction:
-
PVC flat hose rolls up into tight coils for easy storage and transport
-
-
General Applications: Agriculture, Construction, Drip irrigation, Industrial
-
Benefits: Economical, offers excellent UV resistance, available in 300' continuous lengths
-
*Also available in IS series - premium heavy duty discharge*


Available in
1 -1/2" I.D. through 16" I.D.
WST - Heavy Duty PVC Suction & Discharge


-
Service Temperature Range: -4° F to 150°F
-
Construction:
-
Cover & tube - Double ply PVC
-
Reinforcement - polyester fabric reinforcement and rigid PVC helix
-
-
General Applications: Fish suction, Irrigation lines, Trash pumps, Rental and construction dewatering
-
Benefits: Rigid outer helix design protects hose tube from cover wear, and allows hose to slide
-
*Also available in WST-SLR series formulated with advanced UV protection*
Available in
1-1/2" I.D. through 8" I.D.


TIGERGREEN - EPDM Suction

-
Service Temperature Range: -40°F to 160°F
-
Construction:
-
EPDM tube with polyethylene helix
-
-
Full Vacuum Rating
-
General Applications: Septic & waste water handling, Trash pumps, Agriculture liquid fertilizers, Liquid manure handling, Irrigation lines
-
Benefits: Rigid helix design protects hose tube from cover wear, and allows hose to slide easily over rough surfaces and around corners
Available in
1" I.D. through 6" I.D.

BLUEWATER - Low Temp PVC Suction

Available in
3/4" I.D. through 6" I.D.
-
Service Temperature Range: -40°F to 150°F
-
Construction:
-
PVC tube with rigid PVC helix, smooth outer cover (Sizes 3/4" - 4") , Convoluted outer cover (Sizes 5" & 6")
-
-
General Applications: Extreme cold conditions, pumps - rental and construction dewatering, Water suction
-
Benefits: "Cold-flex" materials - hose remains flexible in sub-zero temperatures, Rated for full vacuum up to 4" I.D.

T350LL - Premium Wash Down Hose

-
Working Pressure: 225 PSI [For Steam: 90 PSI]
-
Service Temperature Range: -40°F to 248°F
-
Construction:
-
EPDM cover & tube. Meets FDA and 3A requirements
-
-
General Applications: Washdown service, using hot water or low pressure saturated steam in processing plants and facilities in food and dairy plants.
-
Benefits: Heat, abrasion and ozone resistant
Available in
1/2" I.D. through 1" I.D.
7680 - PureWash Washdown Hose

-
Working Pressure: 300 PSI
-
Service Temperature Range: -40°F to 212°F
-
Construction:
-
EPDM cover & tube. FDA compliant tube
-
-
General Applications: Food & Beverage processing plants, Equipment sanitation, preventative maintenance
-
Benefits: Blue or white non-marking cover, smooth cleanable cover
​
​
Available in
1/2" I.D. through 1" I.D.
7263 - EPDM Steam Hose
-
Working Pressure: 261 PSI
-
Service Temperature Range: -40°F to 406°F
-
Construction:
-
Cover - Wrapped EPDM
-
Tube - Black EPDM
-
Reinforcement - Multiple wire braid reinforcement
-
-
General Applications: ​​Saturated & Superheated steam, Cleaning containment vessels & manufacturing equipment, cleaning & heating process equipment

Available in
1/2" I.D. through 2" I.D.
T341AA/AH - Chlorobutyl Steam Hose
-
Working Pressure: 270 PSI
-
Service Temperature Range: -40°F to 410°F
-
Construction:
-
Cover - Red or black EPDM, wrapped cover fabric impression, pin-pricked to allow venting
-
Tube - Black extruded CIIR
-
Reinforcement - High tensile steel wire braids
-
-
General Applications: Transfer of saturated & superheated steam in shipyards, chemical plants and industrial applications

Available in
1/2" I.D. through 2" I.D.
T605AA - Tank Truck

-
Working Pressure: 150 PSI
-
Service Temperature Range: -22°F to 176°F
-
Construction: Cover - Black CR ; abrasion, ozone & hydrocarbon resistant​​
-
Tube - Black conductive NBR​
-
Reinforcement - High tensile textile cords with flexible steel helix wire
-
-
General Applications: Suction and discharge applications in truck and tank car transfer of gasoline, oil and other petroleum-based products with up to 50% aromatic content​
​
Available in
3/4" I.D. through 8" I.D.
GAMMAFLEX OVAC - Corrugated Oilfield

-
Working Pressure: 150 PSI
-
Service Temperature Range: -20°F to 180°F
-
Construction:
-
Cover - Black, SBR/ Nitrile blend compounded for oil and ozone resistance (corrugated)​​
-
Tube - Black, specially compounded elastomer; low oil swell​
-
Reinforcement - High tensile tire cord plies; dual helix wire
-
-
General Applications: Rugged oilfield service where full suction and working pressures are required. Corrugated cover for improved flexibility
​
Available in
2" I.D. through 6" I.D.
7094(Black) 7095(Red) - MPT II

-
Working Pressure: 200 PSI
-
Service Temperature Range: -20°F to 212°F
-
Construction:
-
Cover - Black or Red Chloroprene, smooth finish​​
-
Tube - Black nitrile; ARPM class A oil resistance​
-
Reinforcement - Multiple textile plies
-
-
General Applications: Air, Mild chemicals, Oil, Water, Cooling lines, Lubrication systems, Agriculture, Foundries, General industrial
​
Available in
1/4" I.D. through 1-1/2" I.D.
7107 - Grizzly

-
Working Pressure: 500 PSI
-
Service Temperature Range: -40°F to 212°F
-
Construction:
-
Cover - Yellow nitrile / PVC ; smooth finsih​​
-
Tube - Black nitrile; ARPM Class A oil resistance
-
Reinforcement - Multiple aramid plies
-
-
General Applications: Air, Oil, Mild chemicals, Water, Agriculture, Construction, Foundries, General industrial, Mines
Available in
1/4" I.D. through 2" I.D.
T604AA - SAE 100R4 Oil Return

​
-
Service Temperature Range: -40°F to 212°F
-
Construction:
-
Cover - Black CR - oil, fuel, weather, ozone and abrasion resistant​​
-
Tube - Black conductive NBR
-
Reinforcement - High tensile textile cords with flexible steel helix wire
-
-
General Applications: Low pressure return lines or suction lines, Service with petroleum based hydraulic fluids, Oil, Lubricants, Crude oil, Fuel oils, and water
-
Benefits: Half the bend radius requirements of SAE J517 100R4
Available in
3/4" I.D. through 2" I.D.
K7560 - PolySpring Oil
-
Oil Resistant Food & Beverage vacuum, suction & Transfer hose
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
Clear phthalate free PVC compound formulated with ingredients in compliance with applicable FDA requirements. Meets NSF and RoHS criteria. Reinforced with helically-wound spring steel wire
-
-
General Applications: Transfer of oily food products such as olive, sunflower, soybean and peanut oils, Transfer of petroleum based oils, Grease suction

Available in
1/2" I.D. through 3" I.D.
SWC693 - Corrugated Chemical Hose

-
Working Pressure: 250 PSI
-
Service Temperature: -40°F to 180°F
-
Construction:
-
Cover - Green EPDM ; corrugated wrapped finish​
-
Tube - UHMWPE
-
Reinforcement - Multiple textile plies with dual wire helix
-
-
General Applications: Acids, Solvents, Chemicals, In-plant and tank transfer, delivery and transport
-
Benefits: Designed to handle the vast majority of commonly used acids, chemicals and solvents. The UHMWPE liner tube will not leach into and contaminate the product being conveyed. The hose construction incorporates a dual wire helix that provides full suction capability, superior kink resistance, and excellent bend radius
Available in
1" I.D. through 4" I.D.
VERSILON TS - SS Braided, Smooth PTFE

-
Working Pressure: 900 PSI up to 3,000 PSI ( Depending on size )
-
Service Temperature: -100°F to 450°F
-
Construction:
-
Cover - 304 Stainless Steel Braid
-
Tube - White smooth PTFE
-
-
General Applications: Compressed gas transfer, Compressed gas cylinder filling, Sanitary fluid transfer, Steam transfer, Gas analysis, Hydraulic lines, Injectable material & adhesive conveying
-
Benefits: Compliant with FDA 21CFR 177.1550 & US Pharmacopeia Class VI, Neutral to taste, color & odor, non-sticking, non-contaminating, Easy cleanability​​
Available in
1/8" I.D. through 1-1/2" I.D.
VERSILON WCS - SS Braided, Convoluted PTFE

-
Working Pressure: 600 PSI up to 2,200 PSI ( Depending on size )
-
Service Temperature: -165°F to 450°F
-
Construction:
-
Cover - 304 Stainless Steel Braid
-
Tube - White Convoluted PTFE
-
-
General Applications: Chemical transfer, Steam transfer, Solvent transfer, Acid lines, Adhesive transfer, CIP lines, Food and beverage transfer
-
Benefits: Compliant with FDA 21CFR 177.1550 & US Pharmacopeia Class VI, Neutral to taste, color & odor, non-sticking, non-contaminating, Easy cleanability, Superior flexibility​​
Available in
3/8" I.D. through 2" I.D.
CORROLINE PLUS - Chemical Fluid Transfer
​​
-
Construction:
-
Cover - Black EPDM anti-static fireproof over SS braid
-
Tube - PTFE ( white or a black anti-static)
-
-
General Applications: Corrosive chemical applications, multi product applications
-
Benefits: High electrical resistance, Kink resistance while retaining excellent flexibility, FDA & USP Class VI compliant ​​
-
Corroline + is built around a unique PTFE hose liner design, which has a slightly rippled smooth bore inside, but convoluted outside to generate excellent flexibility combined with hoop strength. 1" to 3" bore sizes includes a stainless helical wire is wound in to the external convolutions, which adds to the kink resistance, crush resistance and the resistance of the hose to both pressure and vaccuum

Available in
1/2" I.D. through 3" I.D.
Crimp Ferrule
Grade 304 Stainless
Steel Wire Braid
1" to 3" bore sizes include Helical wire evenly pitched and encapsulated in rubber cover
EPDM rubber cover
EN 16643
PHARMALINE N - Smoothbore PTFE
​
-
Construction:
-
Cover - Platinum cured white silicone over SS braid
-
Tube - PTFE liner tube, smoothbore inside, convoluted outside ( white or black anti-static)
-
-
Service Temperature: -100° F up to 400° F
-
Vacuum Limitations: Usable at vacuum to -0.9 Bar for all sizes up to 302°F
-
General Applications: Pharmaceutical, Biotech, Fine chemical manufacturing and research plants
-
Benefits: Chemical resistant, Kink resistant, Self cleaning, Flexible, Hygienic, USP Class VI & FDA 21 CFR 177.1550​​

Available in
1/4" I.D. through 3" I.D.
316 Stainless Steel Wire Braid
PTFE Liner Tube, Externally Convoluted, Internally Smoothbore
316 Stainless Steel Wire Helically Wound Into Convolutions
White Platinum Cured Silicone Rubber Cover
EN16643
CORROFLON - PTFE Process Fluid Transfer
​
-
Construction:
-
Cover Options - SS Braid, Poly Braid, EPDM, Silicone, PVDF Braid
-
Tube - Convoluted PTFE (White or Black Anti-static) with helical reinforcement
-
-
General Applications: Chemical transfer, Pharmaceutical, Biotech, Fine chemical manufacturing and research plants
-
Benefits: Fully Kink & vacuum resistant, light weight, shallow convolutions allowing cleanability and flow while maintaining high flexibility, USP Class VI & FDA ​​
-
​Corroflon will give better cleanability and drainability than any other convoluted PTFE hose on the market. This is because Corroflon is designed and manufactured in such a way that the angle of the convolutions is extremely shallow at 80° to 120° , compared with only 45° to 65° in other convoluted hose designs.

Stainless Steel
Wire Braid
Stainless Steel
Helical Wire
Available in
1/2" I.D. through 6" I.D.
Convoluted PTFE Tube Liner
Helical Wire turned 90°
and welded to
fitting
BIOFLEX ULTRA - PTFE BioTech & Pharmaceutical Fluid Transfer
​
-
Construction:
-
Cover Options - SS Braid, Poly Braid, EPDM, Silicone, PVDF Braid
-
Tube - Smooth PTFE (White or Black Anti-static) , externally convoluted for ultimate flexibility while maintaining a mirror smooth internal finish
-
-
General Applications: Chemical transfer, Pharmaceutical, Biotech, Fine chemical manufacturing and research plants
-
Benefits: Hygienic cleanability, High flow rates, Self draining, No toxic adhesives used in the construction, High flexibility, Permanently resistant to steam sterilizing, Kink resistant, USP class VI & FDA

316 Stainless Wire Helically Wound Into Convolutions
Available in
3/8" I.D. through 3" I.D.
PTFE Tube, Externally Convoluted, Internally Smoothbore
EPDM Rubber Cover
EN16643
Stainless Steel Wire Braid
HYPERLINE FX - PTFE Smoothbore Flexible Hose
​
-
Construction:
-
Cover Options - SS Braid, Aramid Fibre Braid
-
Tube - Smooth PTFE (White or Black Anti-static) , externally convoluted for ultimate flexibility while maintaining a mirror smooth internal finish
-
-
General Applications: Automotive or motorsport, Refrigeration, Steam and gas lines, Industrial and chemical applications
-
Benefits: There is a fundamental problem with larger sizes of standard, smooth bore PTFE hose products - as the hose size increases it becomes significantly less flexible and more easily kinked. One solution is to use a conventional convoluted PTFE lined hose, but the internal convolutions can reduce flow rates. Hyperline FX is a new revolutionary solution to these problems, providing a unique and patented hose liner design which is flexible in the larger bore sizes.

Grade 304 Stainless Steel
Wire Braid
PTFE liner is
internally smooth for cleanability & fast flow
Grade PTFE liner is externally convoluted
for extra flexibility
Available in
1/4" I.D. through 1" I.D.
TR1 - Heavy Duty Abrasion
-
Service Temperature Range: -40°F to 150°F
-
Construction: SBR rubber static dissipative tube with rigid PVC helix​
-
General Applications: Fly ash collection, Grain handling, Hydro excavation, Industrial vac equipment, Material handling - heavy duty abrasive, Rock, gravel, sand and crushed concrete vac, Sewer truck boom, Shot blast recovery, Slurry handling
-
Benefits: Hose remains flexible in sub-zero temperatures, Static dissipative tube, excellent abrasion resistance, light-weight & flexible
​
​

Available in
1-1/2" I.D. through 8" I.D.
T614AA - Hot Tar & Asphalt
-
Service Temperature Range: -4°F to 356°F
-
Working Pressure: 150 PSI
-
Construction:
-
Cover: Black CSM - abrasion, ozone, and hot tar resistant​
-
Tube: Black NBR
-
-
Reinforcement: High tensile textile cords with teel helix wire
-
General Applications: Hot tar & asphalt suction and discharge
​
​

Available in
2" I.D. through 4" I.D.
VLT-SD - VoltBuster

​
-
Service Temperature Range: -40°F to 150°F
-
Construction: Static dissipative polyurethane tube, polyester fabric reinforcement, rigid helix and grounding wire.
-
General Applications: Bulk truck & railcar unloading, FDA material handling, milling machine scrap recovery, Plastic processing equipment, Pneumatic conveying equipment, Suction & discharge
-
Benefits: Abrasion resistant plus, "cold flex" materials, Easy slide helix, FDA compliant, Oil resistant & Static Dissipative
​
Available in
2" I.D. through 8" I.D.



LKC - Lawn King
-
Service Temperature Range: -20°F to 150°F
-
PVC Ducting/ Material handling
-
Construction: PVC tube with rigid PVC helix
-
General applications: Dust collection, Lawn & leaf collection, Light duty material handling
-
Benefits: Rigid helix design protects hose tube from cover wear, and allows hose to slide easily over rought surfaces
Available in
4" I.D. through 8" I.D.


T760AA - Dry Powder Delivery (Softwall)
-
Service Temperature Range: -22°F to 176°F
-
Working pressure: 75 PSI
-
Construction:
-
Cover​ - Black conductive SBR/NR blend - abrasion and ozone resistant
-
Tube - 3/16" black static conducting NR
-
Reinforcement: Spiraled high tensile textile cords General applications: Dry cement, Grains, and animal feed transfer
-
-
General Applications: Dry cement, Grains, and animal feed transfer
Available in
4" I.D. through 6" I.D.

UFC - Ureflex Heavy Duty Material Handling
-
Service Temperature Range: -40°F to 150°F
-
Working pressure: 35-50 PSI
-
Construction:
-
Cover​ - PVC
-
Tube - Polyurethane
-
Reinforcement: Rigid PVC helix
-
-
General applications: Agricultural dry fertilizer, Air seeder lines, Industrial vacuum equipment, Material handling - heavy duty abrasive, Milling machine scrap recovery, Plastic processing equipment, Shot blast recover
-
Benefits: Thick abrasion resistant polyurethane line, Static Dissipative cover, Phthalate free, Oil resistant liner
Available in
1-1/2" I.D. through 4" I.D.
WE SERIES - Food Grade PVC Material Handling Hose With Grounding Wire

Available in
1" I.D. through 8" I.D.
-
Service Temperature Range: -4°F to 150°F
-
Construction:
-
PVC tube with rigid PVC helix and grounding wire with a convoluted outer cover
-
Grounding Wire - Multi-strand wire helps prevent the build up of static electricity embedded within the rigid helix to prevent contamination of transferred materials
-
-
General Applications: Food grade material handling - standard duty, Pharmaceutical product transfer, Plastic processing equipment, Pneumatic conveying equipment
-
Benefits: Hose complies with applicable FDA(03) requirements. Hose approved by USDA(12) for use in meat and poultry plants


K1134 - PolyAir
-
Multi-purpose Air & Water
-
Construction:
-
PVC cover & tube, yarn reinforcement
-
-
General Applications: Transfer of air, water or mild water soluble chemicals, Outdoor applications requiring a low temperature hose, General air supply line for pneumatic tools and paint spray systems, Low pressure spray hose for water-soluble chemicals
-
Benefits: UV & weather resistant, Ideal for in-plant applications requiring color coding of hose supply lines

Available in
1/4" I.D. through 1" I.D.
T902AA - Hot Air Blower

-
Working Pressure: 150 PSI
-
Service Temperature Range: -40°F to 356°F
-
Construction:
-
Black EPDM with spiraled high tensile textile cords with flexible steel helix wire
-
-
General Applications: Hot Air transfer between the air compressor and dry bulk tank on bulk material carriers
Available in
2" I.D. through 4" I.D.
T155AK - Compressed Air

-
Working Pressure: 300 PSI
-
Service Temperature Range: -22°F to 176°F
-
Construction:
-
Cover - Yellow SBR (abrasion and ozone- resistant)​
-
Tube - Black SBR/BR blend - oil mist resistant
-
Reinforcement - Spiraled, high tensile textile cords
-
-
Applications: High quality air hose for mining and construction service
Available in
1/2" I.D. through 4" I.D.
T140AK - Braided Steel Wire Air

-
Working Pressure: 600 PSI
-
Service Temperature Range: -22°F to 176°F
-
Construction:
-
Cover - Yellow SBR - pin pricked​
-
Tube - Black SBR - oil mist resistant
-
Reinforcement: High tensile steel wire braids
-
-
Applications: High pressure air hose for heavy-duty use in mines, quarries, construction and industry
Available in
1/2" I.D. through 4" I.D.

Available in
1/4" I.D. through 2" I.D.
7092/ 7093 - GST General Service
-
Working Pressure: 200 PSI
-
Service Temperature Range: -40°F to 212°F
-
Construction:
-
Cover - Black or red EPDM; smooth finish​
-
Tube - Black EPDM
-
Reinforcement - Multiple textile plies
-
-
General Applications: Versatile general purpose hose designed to handle air, mild chemicals and water, Agriculture, Construction, and General industrial
-
Note: Not recommended for vacuum applications or use with oil or refined fuel
K7160 - Polyspring

Available in
1/4" I.D. through 3" I.D.
-
PVC Food & beverage vacuum/ transfer hose
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
PVC compound, formulated with ingredients in compliance with applicable FDA requirements, meets USDA, 3A, NSF, UL, USP and RoHS criteria. reinforced with helically-wound spring steel wire
-
-
General Applications: Full vacuum lines, Industrial vacuum pumps, Food & beverage dispensing, Air & water supply lines, Pneumatic parts transfer, Car wash applications, coolant lines, Air breathing lines, Deionized water systems
7212 - Multipurpose Push-on Hose
-
Service Temperature Range: -40° F to 212°F (158°F for Air)
-
Construction:
-
Cover - Black, blue, gray, green, red or yellow chloroprene; smooth finish​
-
Tube - Black nitrile - ARPM class A oil resistance
-
Reinforcement - One textile braid
-
-
General Applications: Air, Mild chemicals, Oil, Water, Diesel, Ethanol, Gasoline, Air operated paint systems, Air tools, Transfer lines, Agriculture, Construction, Automotive, Factory color-coded assembly equipment

Available in
1/4" I.D. through 3/4" I.D.
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
Clear phthalate free PVC compound formulated with ingredients in compliance with applicable FDA and RoHS requirements
-
-
General Applications: Air conditioning drainage, refrigeration drainage, air lines, Printing press equipment, High efficiency furnace drainage, Transfer of weak chemicals and acids
-
Features: High gloss clear appearance with glass smooth interior to reduce sediment buildup, FDA compliant Phthalate free PVC compound, Self-extinguishing, Compound hardness 75 ± shore "A"

Available in
1/8" I.D. through 2" I.D.
K050 - Clear PVC Tubing
FGR - Food Grade Rubber
-
Service Temperature Range: -40°F to 250°F
-
Construction:
-
Cover - Grey EPDM​
-
Tube - White nitrile- PVC blend
-
Reinforcement - galvanized carbon steel helix wire
-
-
General Applications: Process transfer, Washdown stations, Hot CIP transfers, Load cell connections, Pump vibration damping, Ground meat, Bulk foods
-
Benefits: Premium quality sanitary suction & discharge, specially designed to handle oil based materials, Full vacuum rating

Available in
1/2" I.D. through 4" I.D.
T720LG - Bulk Food Suction & Discharge
-
Service Temperature Range: -22°F to 176°F
-
Construction:
-
Cover - Green SBR / EPDM blend​
-
Tube - 3/16" white FDA natural rubber - abrasion resistant
-
Reinforcement - Spiraled high tensile textile cords with flexible steel helix wire and static wire
-
-
General Applications: Suction & discharge of wet or dry abrasive materials. Designed for grains, flour & pellet transfer

Available in
2" I.D. through 8" I.D.
6507NB - NovaBrew

-
Service Temperature Range: -40°F to 240°F
-
Construction:
-
Cover - Dark burgundy EPDM​
-
Tube - White chlorobutyl
-
Reinforcement - Multiple plies of polyester tire cord, dual monofilament helix rods
-
-
General applications: non-oily food & beverage transfer
-
Benefits: Designed based on the specific requirements of the modern day brewery, microbe resistant, easily cleanable, meets FDA USDA and 3-A
Available in
3/4" I.D. through 2-1/2" I.D.
FT - FDA PVC Suction
-
Service Temperature Range: -4°F to 150°F
-
Construction:
-
PVC tube with rigid PVC helix
-
-
General Applications: Food grade liquids such as potable water, beer, wine & Food grade material handling - standard duty, Ice transfer, Milk & dairy product transfer, Poultry processing, Water suction
-
Benefits: Phthalate free, complies with FDA and 3-A requirements, approved by USDA for use in meat & poultry plants

Available in
3/4" I.D. through 8" I.D.

K7560 - PolySpring Oil

-
Oil Resistant Food & Beverage vacuum, suction & Transfer hose
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
Clear phthalate free PVC compound formulated with ingredients in compliance with applicable FDA requirements. Meets NSF and RoHS criteria. Reinforced with helically-wound spring steel wire
-
-
General Applications: Transfer of oily food products such as olive, sunflower, soybean and peanut oils, Transfer of petroleum based oils, Grease suction
Available in
1/2" I.D. through 3" I.D.
K3150 - ClearBraid PVC Food & Beverage

-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
Clear phthalate free PVC compound, formulated with ingredients in compliance with applicable FDA requirements, meets USDA, 3A, NSF, UL, RoHS, and USP class VI criteria. Reinforced with spiraled polyester yarn
-
-
General Applications: Food & beverage dispensing, Deionized water, Liquid food products, Air & water lines, Potable water transfer, Air breathing lines, Pneumatic lines, Packing machines
Available in
3/16" I.D. through 2" I.D.
2020 SERIES - FDA Polyurethane Material Handling
-
Service Temperature Range: -40°F to 150°F
-
Construction:
-
Cover - Polyurethane with Rigid outer helix to protect tube from wear
-
Tube - Extra thick double-ply polyurethane tube, polyester fabric reinforcement, rigid PVC helix and grounding wire
-
-
General Applications: Bulk truck and railcar unloading, Food grade material handling - heavy duty abrasive, Suction & discharge

Available in
2" I.D. through 8" I.D.

WE SERIES - Food Grade PVC Material Handling Hose With Grounding Wire


Available in
1" I.D. through 8" I.D.
-
Service Temperature Range: -4°F to 150°F
-
Construction:
-
PVC tube with rigid PVC helix and grounding wire with a convoluted outer cover
-
Grounding Wire - Multi-strand wire helps prevent the build up of static electricity embedded within the rigid helix to prevent contamination of transferred materials
-
-
General Applications: Food grade material handling - standard duty, Pharmaceutical product transfer, Plastic processing equipment, Pneumatic conveying equipment
-
Benefits: Hose complies with applicable FDA(03) requirements. Hose approved by USDA(12) for use in meat and poultry plants
MEDIUM PRESSURE HYDRAULIC OIL LINES
SAE 100R17 WEARGUARD PLUS
-
3,000 PSI
-
Temp Range: -40°F to 250°F
-
Tube: Black, oil resistant, Nitrile​
-
Reinforcement: One wire high tensile steel braid in sizes 1/4" thru 1/2". Two wire high tensile Steel braid in sizes 5/8" thru 1"
-
WearGuard cover: Black, oil and extreme abrasion resistant neoprene. MSHA approved

HIGH PRESSURE HYDRAULIC OIL LINES
SAE100R12 FLEX PLUS 4 SPIRAL
-
2,500 PSI - 4,000 PSI
-
Temp Range: -40°F to 250°F
-
Heavy duty service applications with crude oils, fuel oils, lube oils, & gasoline. Exceeds SAE100R12 performance and half bend radius. High impulse life
-
Tube : Black, oil resistant, Chloroprene
-
Reinforcement: Four plies of spirally wrapped high tensile steel wire
-
Cover: Chloroprene

MEDIUM PRESSURE HYDRAULIC OIL LINES
SAE 100R16 WEARGUARD PLUS
-
2,400 PSI- 5,800 PSI
-
Temp Range: -40°F to 250°F
-
Tube: black, oil resistant, Nitrile
-
Reinforcement: Two wire braid of high tensile steel
-
Wearguard Cover: Black, oil and extreme abrasion resistant Neoprene

EXTRA HIGH PRESSURE HYDRAULIC OIL LINES
SAE 100R13 ~ 4 AND 6 SPIRAL
-
5,000 PSI
-
Temp Range: -40°F to 250°F
-
Heavy duty service applications with crude oils, fuel oils, lube oils, and gasoline. Meets or exceeds SAE 100R13
-
Tube: Black, oil resistant, Neoprene
-
Reinforcement: Multiple plies of spirally wrapped high tensile steel wire
-
Cover: SBR/EPDM weather & temperature resistant. MSHA approved


Available in
1/4" I.D. through 2" I.D.
7092/ 7093 - GST General Service
-
Working Pressure: 200 PSI
-
Service Temperature Range: -40°F to 212°F
-
Construction:
-
Cover - Black or red EPDM; smooth finish​
-
Tube - Black EPDM
-
Reinforcement - Multiple textile plies
-
-
General Applications: Versatile general purpose hose designed to handle air, mild chemicals and water, Agriculture, Construction, and General industrial
-
Note: Not recommended for vacuum applications or use with oil or refined fuel
K7160 - Polyspring

Available in
1/4" I.D. through 3" I.D.
-
PVC Food & beverage vacuum/ transfer hose
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
PVC compound, formulated with ingredients in compliance with applicable FDA requirements, meets USDA, 3A, NSF, UL, USP and RoHS criteria. reinforced with helically-wound spring steel wire
-
-
General Applications: Full vacuum lines, Industrial vacuum pumps, Food & beverage dispensing, Air & water supply lines, Pneumatic parts transfer, Car wash applications, coolant lines, Air breathing lines, Deionized water systems
7212 - Multipurpose Push-on Hose
-
Service Temperature Range: -40° F to 212°F (158°F for Air)
-
Construction:
-
Cover - Black, blue, gray, green, red or yellow chloroprene; smooth finish​
-
Tube - Black nitrile - ARPM class A oil resistance
-
Reinforcement - One textile braid
-
-
General Applications: Air, Mild chemicals, Oil, Water, Diesel, Ethanol, Gasoline, Air operated paint systems, Air tools, Transfer lines, Agriculture, Construction, Automotive, Factory color-coded assembly equipment

Available in
1/4" I.D. through 3/4" I.D.
-
Service Temperature Range: 25°F to 150°F
-
Construction:
-
Clear phthalate free PVC compound formulated with ingredients in compliance with applicable FDA and RoHS requirements
-
-
General Applications: Air conditioning drainage, refrigeration drainage, air lines, Printing press equipment, High efficiency furnace drainage, Transfer of weak chemicals and acids
-
Features: High gloss clear appearance with glass smooth interior to reduce sediment buildup, FDA compliant Phthalate free PVC compound, Self-extinguishing, Compound hardness 75 ± shore "A"

Available in
1/8" I.D. through 2" I.D.
K050 - Clear PVC Tubing
BLUEWATER - Low Temp PVC Suction

-
Service Temperature Range: -40°F to 150°F
-
Construction:
-
PVC tube with rigid PVC helix, smooth outer cover (Sizes 3/4" - 4") , Convoluted outer cover (Sizes 5" & 6")
-
-
General Applications: Extreme cold conditions, pumps - rental and construction dewatering, Water suction
-
Benefits: "Cold-flex" materials - hose remains flexible in sub-zero temperatures, Rated for full vacuum up to 4" I.D.
Available in
3/4" I.D. through 6" I.D.

Airduc PUR 350 FOOD-AS
-
Material: Permanently anti static FDA premium ether-polyurethane with spring steel wire
-
Temp Range: -40°F to 195°F
-
Wall thickness: 0.0275"
-
Abrasive powder, bulk material, granulate & gases​, conveying dry foods
-
Explosion hazard area, Clean room ventilation, semiconductor production machine
-
Paper mill, paper and pulp industry: waste water, air extraction
-
Medical Equipment
-

Master TPR plus
-
Material: Thermoplastic elastomer fabric reinforced with spring steel wire.
-
Temp Range: -60°F to 275°F
-
Wall thickness: 0.02"
-
Applications:
-
Dust collection on woodworking equipment​
-
Fume extraction/ welding arm
-
Drying/ plastics equipment
-
Air-conditioning / ventilation systems
-
Light mat handling
-
Drain & general purpose applications
-
​
​

Airduc PUR 351 FOOD
-
Material: FDA Premium ether-polyurethane with spring steel wire
-
Temp Range: -40°F to 195°F
-
Wall thickness: 0.04"
-
Applications:
-
Abrasive powder, bulk material, granulate & gases​
-
Food industry, pharmaceutical industry
-
Conveying of dry foods
-
Vacuum conveying equipment, vacuum hopper, suction conveyor, dosing system, industrial vacuum cleaners
-
Mixer, dryer, packing machine​
-

Genesis STM
"I-HELIX"
-
Material: Polyethylene copolymer hose reinforced with an integral polyethylene helix
-
Temp Range: -40°F to 160°F
-
Applications:
-
Carpet floor cleaning​
-
Marine sanitation
-
Pumper
-
Sewer & waste
-
Wet pick-up
-
-
Features: Double profile I-Helix construction for easy movement, Crush resistant, All sizes handle full vacuum, smooth interior assures efficient air flow
